NOTE: You may require the assistance of
another person for this step.
Carefully lay down the cabinet on its back with
a soft mat underneath to protect the finish.
Position the two rigid castors (7) on the
bottom of the cabinet on the left side. Insert the
M8 x 20 hex bolts (5) through the the castors
and into the bottom of the cabinet.
Tighten securely.
Repeat for the two swivel castors (4) on the
other side. The handle must be mounted on
the same side of the cabinet as the swivel castors.
Wrench tighten all screws. Return the cabinet to
its upright position.
8
headline bars
continuation tabs
notes
warnings
model no. 058-6551-6, 058-6552-4 I contact us 1-800-689-9928
NOTE: The holes in the cabinet are tapped and
therefore require no nuts for installation.
Position the cabinet handle (1) over the
holes and attach with the M6 x 12 bolts (2).
Tighten securely.
