OPERATING INSTRUCTIONS
16
AIR-POWERED STAPLER 058-8132-2
3. Slide the pusher against the staples to
close the magazine (1) until it comes
into contact with the staples and locks
into place
(fig C)
.
4. Plug in compressor, turn it on, set the
pressure regulator to 90 psi, attach one
end of the air hose to the compressor
and the other end of the air hose (1) to
the tool (2)
(fig D)
. page 11
(wood density chart)
1
MC-8132-05
fig C
MC-8132-06
1
fig D
2
WARNING!
Potential hazard that could result in serious injury or loss of life.
• The safety tip must be in contact with the workpiece before activating the
tool.
• Do not operate the tool if the staples are not loaded, as doing so may
damage the tool.
• Do not fire staples into the air, as doing so may cause injury to the operators
or others, apart from damaging the tool.
• Load the correct type of staples only, do not load different sized staples into
the magazine, as doing so may cause staples to jam. Failure to comply
could lead to serious injury or loss of life.
