TROUBLESHOOTING
23
AIR-POWERED STAPLER 058-8132-2
Note: For further repair information, please call 1-800-689-9928.
The tool does not
operate properly – it
does not drive the
staples or operates
sluggishly.
1. The air supply is inadequate.
2. Lubrication is inadequate.
3. The O-rings or seals are worn or
damaged.
4. The exhaust port in the cylinder
head is blocked.
1. Verify that the air supply is adequate.
2. Pour up to 6 drops of oil into the air inlet.
3. Inspect and replace O-rings or seals.
4. Replace the damaged internal parts.
Have the tool serviced by a qualified service
technician.
The tool skips
staples.
1. The bumper is worn or the spring
is damaged.
2. There is dirt in the front plate.
3. Staples cannot move freely in the
magazine because of dirt or
damage.
4. The O-ring on the piston is worn
or dry or there is not enough
lubrication.
5. The cylinder cover seal Is leaking.
1. Replace the bumper or pusher spring.
2. Open the drive channel on the front plate and
clean the plate.
3. Clean the magazine.
4. Replace the O-ring or pour up to 6 drops of
oil into the air inlet
.
5. Replace the sealing washer.
Have the tool serviced by a qualified service
technician.
The tool jams.
1. Improper staples are used, or
staples are damaged.
2. The driver guide is damaged or
worn.
3. The magazine or safety tip is
loose.
4. There is dirt in magazine.
See section “Clearing a jammed staple”.
1. Use the proper staple.
2. Inspect and replace the driver.
3. Tighten the magazine and safety tip.
4. Open and clean the magazine.
Air exhaust is being
directed towards the
operator.
The direction of the exhaust port
requires adjustment.
Direct the exhaust port away from the operator.
PROBLEM POSSIBLE CAUSES SOLUTIONS
