PARTS LIST
26
AIR-POWERED STAPLER 058-8132-2
No. Description Qty. No. Description Qty.
1 Bolt M5 X 20 6 27 Spring 1
2 Spring washer 6 28 Trigger pin 3
3 Cylinder cover 1 29 Trigger 1
4 Seal washer 1 30 Pin 2.5 X 16 1
5 Compressed spring 1 31 Trigger plate 1
6 O-ring 13.7 X 2.4 1 32 WCE guide 1
7 Head valve 1 33 Spring 1
8 Washer 1 34 Safety yoke 1
9 O-ring 24.8 X 3.5 1 35 Pin 3 X 16 1
10 O-ring 31.2 X 2.5 1 36 Quick release handle 1
11 O-ring 41.7 X 3 1 37 Driver guide cover 1
12 Collar 1 38 Spacer 1
13 O-ring 26.2 X 2.4 1 39 Driver guide 1
14 Cylinder 1 40 Pin 1.5 X 10 1
15 O-ring 21 X 3.0 1 41 Bolt M4 X 14 2
16 Main piston 1 42 Fixed magazine 1
17 Bumper 1 43 Pusher 1
18 Rubber washer 1 44 Pusher pipe 2
19 Gun body 1 45 Compressed spring 2
20 Rubber washer 1 46 Fixed block 1
21 Rectangle washer 12.9 X 7.0 X 1.8 1 47 Bolt M4 X 6 3
22 Switch valve seat 1 48 Movable magazine 1
23 Switch valve stem 1 49 Bolt M4 X 5 2
24 O-ring 1.7 X 2.0 4 50 Fixed seat 1
25 Trigger valve guide 1 51 Washer 2
26 O-ring 11.2 X 2.0 1 52 Support seat 1
