11
OPERATING INSTRUCTIONS
WARNING!
• In order to avoid pinching your hands or fingers, do not hold the handle bar at the joints.
OPERATING INSTRUCTIONS
UNFOLD THE HANDLE BAR
(fig. 1)
1. Put the product on the ground. Note that it is
delivered with the handle bar in its storage position.
2. Pull the clamp lever outwards, hold it in position,
and then rotate the lower handle bar clockwise to
put the product from storage to working position.
3. Release the clamp lever and keep rotating the
handle bar until the lock pin of clamping lever
engaged in the upper hole or lower hole on the
supporting plate, depending on the required handle
height.
4. Press the unlock button, hold it in position, and
then gradually pull out upper handle bar until the
bar reaches STOP position.
5. Release the unlock button and ensure the upper
handle bar is secured.
fig. 1a
Clamping lever
Upper hole
Lower
hole
Supporting
plate
fig. 1c
Unlock button
Upper
handle
bar
NOTICE:
• Pull or push the upper handle bar gently. Do not use sudden force.
• The upper handle bar can only be secured in its lower or upper position.
• The power can only be activated once the upper handle bar is secured at the STOP position.
fig. 1b
Lower hole
Lock pin
