MasterCraft 099-4119-2 - Assembly and Maintenance; Accessory Assembly Guide

Accessories
Installing Accessories
(See Fig. A)
Fig. A
g
f
e
a
c
b
d
ASSEMBLY
14
The unit is supplied with an accessory kit and inflator/deflator kit. Choose the accessory
needed.
Installing the Tire Chuck
1. Attach the tire chuck (a) to the hose (b), and tighten securely using wrenches.
Installing Accessories
1. Attach the blow gun (c) to the hose (b).
2. Attach the safety nozzle (d) or the blow gun adaptor (e) to the blow gun.
NOTE: To use the inflation needle (f) or the tapered inflation nozzle (g), the blow gun adaptor
(e) must be attached to the blow gun.
3. Attach the inflation needle (f) to the blow gun adaptor on the blow gun.
