2007 MasterCraft Owners Manual - Page 4-1
Model Feature Located
ProStar 190, ProStar 197, X-1, X-7 Battery Beneath observer seat
MariStar 200, X-2, MariStar 230, X-30, Batteries Beneath rear port seat
MariStar 280, X-80
MariStar 245, X-45 Batteries Beneath rear starboard seat
X-Star Batteries Beneath rear port and starboard seats
All Models Blower Exhaust Transom
All Models Bow Light(s) Forward top of bow deck
All Models Circuit Breakers Beneath instrument panel; additional
breakers may be near battery box
ProStar 190, ProStar 197, X-7 Drain Plug Access through deck forward of
engine compartment
MariStar 200, X-1, X-2, MariStar 230, X-30, Drain Plug Access through deck mid-ship, forward
MariStar 245, X-45, MariStar 280, X-80, X-Star of rear seating
ProStar 190, ProStar 197, X-7 Engine compartment Amidship center of deck
MariStar 200, X-1, X-2, MariStar 230, X-30 Engine compartment Aft, beneath sun deck
MariStar 245, X-45, MariStar 280, X-80, X-Star
ProStar 190, ProStar 197, X-7 Fuel tank ller Outside port rear
MariStar 200, X-1, X-2 Fuel tank ller Outside starboard rear
MariStar 230, X-30, MariStar 245, X-45, Fuel tank llers Outside both port and starboard rear
MariStar 280, X-80, MariStar 280 STS, X-Star
All models Glove box Forward of observer seat
All models Instrument panel Forward of driver’s seat
MariStar 200, X-1, X-2 Ski locker Center walk-thru to bow
ProStar 190, ProStar 197, X-7, X-1, MariStars Stern light receptacle Top of starboard rear deck near sun pad
All Models Swim platform Attached to transom
All models Throttle/shift control Starboard side panel beside
driver’s seat
