MasterCraft 54-4892-4

Symbols
V …............ Volts
A ………... Amperes
Hz ……… Hertz
W ………. Watts
kW ........... Kilowatts
........ Microfarads
L ………... Litres
kg ……… Kilograms
H ………... Hours
N/cm
2
....... Newtons per square
centimetre
Pa ……… Pascals
OPM ….. Oscillations per minute
min ……. Minutes
s ………... Seconds
or AC …... Alternating current
.. Three-phase alternating
current
.. Three-phase alternating
current with neutral
….. Read all safety warnings
and instructions
WARNING: Some of the following symbols may appear on the rotary tool. Study
these symbols and learn their meaning. Proper interpretation of these symbols will allow for more
efcient and safer operation of this tool.
!
... Direct current
……….. No load speed
………. Alternating or direct current
………. Class II construction
….......... Splash-proof construction
…….. Watertight construction
………. Protective grounding at
grounding terminal, Class I
tools
… Revolutions or reciprocations
per minute
…........... Diameter
0 ………….. Off position
……. Directional arrow
……... Warning symbol
………. Wear your safety glasses
……... Wear hearing protection
SAFETY GUIDELINES
12
No. Description No. Description
1 Air vents 7 Collet nut
2 ON/OFF speed switch 8 Right angle attachment
3 Hanging loop 9 Right angle attachment drive shaft
4 Replaceable motor brushes 10 L–key
5 Spindle lock button 11 Cutting guide
6 Umbrella nut
KEY PARTS DIAGRAM
13
DELUXE CORDED ROTARY TOOL KIT 054-4892-4
