Component Description
Mode
Selection
Allows the selection of an operating mode:
• Drive: optimized for cruising from place to
place with controls for AutoLaunch, speed,
ballast and tabs.
• Surf: provides access to the four factory
surf profiles (Mellow or Steep, Left or Right),
allows operators to customize surf profiles by
name, ballast level and tab settings.
• Wake: provides access to custom and factory
set wake profiles, AutoLaunch controls and
ballast levels.
• Ski: provides access to custom and factory
set ski profiles, AutoLaunch controls and
ballast levels.
AutoLaunch
Control (Triple
and Single)
When AutoLaunch Single is turned on, the cen-
ter tab is used to help push the boat up to plane.
When AutoLaunch Triple is turned on, all three
tabs are used to help push the boat up to plane.
Tab Controls Provides access to individually adjust tabs.
Fill/Empty All
Ballast
Provides a quick method to fill or empty all of
the ballasts tanks and bags at one time.
Adjust Cruise
Set Speed
Provides adjustment to the cruise control set
speed.
Cruise ON/OFF Turns on and o the speed control system.
Fill/Empty
Ballast Tanks
Provides access to individually adjust each bal-
last zone (center tank and individual side tanks
and bags, midship tank when equipped)
Component Description
Media Provides access to AM/FM/Weather bands, Blue-
tooth and USB media selections.
Audio
Zones
Access to volume zone and equalizer controls for
the entire boat.
Lighting Turn on/o the standard and optional lighting on the
boat.
Heaters Controls for various accessories including the bilge,
heater, seat heaters and blower switches.
Settings Provides access to:
• System Settings
• Bluetooth Manager
• Fuel Management
• Diagnostics
• GPS Settings
• Ballast / Tab Settings
• Service Information
• Factory Settings
Profiles Provides the ability to create and save/store cus-
tom rider profiles.
2021MCOwnerManualFINAL.indd 131 8/26/20 1:52 PM
