MasterCraft Prostar Series

X-
7
AFUEL TAN K FILLER
BBLOWER EXHAUST
CSWIM PLAT FORM
D STERN LIGHT RECEPTACLE
ESTORAGE UNDER SUN PAD
F ENGINE COMPARTMENT
G THROTTLE/SHIFT CONTROL
HINSTRUMENT PANE L
IBOW LIGHT
JGLOVE BOX
K BATTERY (UNDER SEAT)
L DRAIN PLUG
GUIDE TO INDIVIDUAL MODELS: X -7
5-10
I
J
G
F
H
A
C
B
D
E
K
L
AOIL PRESSURE GAUGE
B ENGINE TEMPERATURE GAUGE
C SPEEDOMETER
DMULTI-FUNCTION/TACHOMETER
E CHECK ENGINE LIGHT
F SPEEDOMETER OR PERFECT PASS G AUGE
G VOLTMETER
HFUEL GAUGE
IHORN
J ACCESSORY 1 SWITCH
K ACCESSORY 2 SWITCH
L COURTESY LIGHTS SWITCH
M SPEEDO AJUSTMENT SWITCHES
NCLOCK ADJUSTMENT SWITCH
ONAV/ANCHOR LIGHTS SWITCH
PBILGE PUMP SWITCH
QBLOWER
R IGNITION KEY SLOT
a
b
c
d
f
g
h
j
kl mn op
q
r
e
i
m
LENGTH OF BOAT: .............................................. 19’8”
OVERALL LENGTH W/TRAILER: ............................. 22’8”
LENGTH W/SWING-AWAY TONGUE FOLDED: ............. 21’
WIDTH AMIDSHIP: .................................................... 92”
OVERALL WIDTH W/TRAILER ................................. 100”
BOAT HEIGHT W/WINDSHIELD ......................... 60-1/2”
HEIGHT W/WINDSHIELD & TRAILER (TA) .......... 72-1/2”
HEIGHT W/WINDSHIELD & TRAILER (SA) .................. 74”
HEIGHT W/TOWER FOLDED ON TRAILER (TA) . 84-1/2”
HEIGHT W/TOWER FOLDED ON TRAILER (SA) ......... 86”
BOAT WEIGHT: ............................ 2,800 LBS. (APPROX.)
SINGLE AXLE TRAILER WEIGHT: ......................... 860 LBS.
TANDEM AXLE TRAILER WEIGHT: .................... 1,040 LBS.
FUEL CAPACITY: ......................................... 31 GALLONS
CAPACITY: ................................. 6 PEOPLE OR 900 LBS.
