7
Welding Guidelines (Continued)
cover pass (See Figure 10). If the pieces
are thick, it may be necessary to bevel
the edges that are joined at a 60º
angle. Remember to remove the slag
between each pass.
Figure 10 - Weld Passes
Cover
Filler
Root
Figure 11 - Multiple Weld Passes
WS0973, 58-8023-2
