MasterCraft X22 2023

193
/
2023 OWNER’S MANUAL
Tanks/Tabs
From the Home screen, the Tanks/Tabs screen can be accessed
by pressing the Display Key under TANKS/TABS in the Menu Bar.
Tanks/Tabs Screen Features
• Port NXT Wake Shaping Position
• CTR Attitude Adjustment Plate Position
• STBD (Starboard) NXT Wake Shaping Position
• Cruise ON or OFF
• AutoLaunch ON or OFF
• Enable/disable optional NXT Pro Surf Integrated Ballast Kit
Press the HOME key to return to Home or press the ARROW key to
scroll to other screens.
Main Menu
From the Home screen, the Main Menu screen can be accessed by
pressing the Display Key under MENU in the Menu Bar.
Main Menu Screen Features
• User Settings
• Service Information
• Engine Diagnostics
• Factory Settings
Press the Display Key under the UP and DOWN pointers to scroll
the list and highlight a feature. Press the Display Key under
SELECT to open a feature screen. Press the HOME key to return to
the Home screen or press the ARROW key to scroll to
other screens.
