409
/
2023 OWNER’S MANUAL
An audible “click” will be heard. The latch should close with finger
pressure. If the latch will not close freely, the ball is not fully
inserted into the socket, it is over-sized or egg- shaped, or the
latching mechanism is damaged. DO NOT FORCE THE HANDLE.
If necessary, replace the ball with a quality unit that meets
SAE specifications.
Insert the hitch pin into the hole on the side of the coupler.
The hitch pin will not go in the coupler if the hitch ball is not
seated properly.
DO NOT tow the trailer with the handle open or if the latch handle
will not remain closed. Check to see that the coupler is locked.
If the latch is damaged, contact an authorized MasterCraft dealer
for assistance.
Lights
Before each use make certain that all trailer lights are in proper
working order to reduce the risk of serious injury, death and/or
property damage.
The MasterCraft trailer harness was specifically designed to mate
with the tow vehicle’s equipment. This harness is designed to
disengage the trailer brakes using the tow vehicle’s harness.
NOTE: See an authorized MasterCraft dealer if the tow vehicle
does not have the correct trailer harness.
The trailer lights are brighter when the trailer is submerged.
A sensor notifies the system when the trailer ramp is under water,
and the lights will be at their maximum luminance. When the trailer
is removed from the water, the lights will automatically dim.
There is no consumer control for the system.
To keep trailer lighting system in good
working order:
Be sure the white ground wire is properly connected to the master
cylinder. Replace any parts that are damaged or worn.
