2023 OWNER’S MANUAL
/
68
FEATURES
01. Bow cleat
02. Horn
03. Anchor storage
04. Navigation light
05. Ballast tank below deck
06. Bow sub-woofer
07. ZeroO GPS puck
08. Bilge thru-hull outlet
09. Ballast thru-hull outlet
10. Midship cleat
11. Circuit breaker panel; battery switch
12. Instrument panel
13. Steering wheel
14. Throttle control and emergency stop
switch
15. Fire suppression unit manual override
16. Sub-woofer (where equipped)
17. Heated seat (where equipped)
18. Pop-up back-facing backrest
19. Wireless cockpit chargers (where
equipped)
20. Cooler (under seat)
21. Convertible center rear seating (where
equipped)
22. Ballast thru-hull outlet
23. Stern cleat
24. Fuel tank fill
25. Engine flush valve
26. Engine compartment
27. Bilge outlet
28. Automatic fire extinguisher
29. Transom remote (where equipped)
30. Underwater lights (two, where
equipped)
31. Surf tab (two on either side and one in
center)
32. Navigation light
33. Bow filler cushion (where equipped)
34. Amp
35. Trash can door
36. Handheld fire extinguisher
37. Glove box
38. Observer remote (where equipped)
39. Center drain plug
40. Heated observer seat (where
equipped)
41. Batteries ON-OFF switch
42. Tower with clamping board racks
43. Anchor light and tower tow point
attachment
44. Pylon attachment
45. Batteries (under seat)
46. Ballast thru-hull vents
47. Sun deck flip seating (where equipped)
48. Transom drain plug
49. Swim platform
SPECIFICATIONS
Length of Boat 24’0
Width Amidship 86.5
Boat Weight 5,250 lbs.
Length of Boat w/Platform 260
Towing Length 28’ 3
Towing Width 102
Fuel Capacity 79 gallons
Maximum Capacity 16 people
or 2,500 lbs.
Bow: 5 people or 750 lbs.
Weight must be evenly distributed.
XT23
