2023 OWNER’S MANUAL
/
74
NXT22
FEATURES
01. Navigation light
02. Anchor storage compartment
03. Walk-thru door (where equipped)
04. Ballast thru-hull outlet
05. Bilge thru-hull outlet
06. ZeroO GPS puck
07. Cleat (where equipped)
08. Mirror
09. Stereo control (on dash, where equipped)
10. Circuit breaker panel (access under dash)
11. Tilt steering wheel
12. Instrument panel; wireless helm charging
pad (where equipped)
13. Shifter/throttle control
14. Emergency safety stop switch
15. Fire suppression unit manual override
16. Adjustable driver’s seat
17. Access to center ballast pumps
18. Cooler (beneath seat)
19. Sea strainer (in engine compartment)
20. Cleat (where equipped)
21. Ski pylon (where equipped)
22. Fuel tank filler
23. Automatic fire extinguisher
24. Ballast thru-hull vent
25. Bilge thru-hull vent
26. Transom stereo remote (where equipped)
27. Transom drain plug
28. Center surf tab
29. Navigation light
30. Courtesy light
31. Amp
32. Cleat (where equipped)
33. Glove box
34. Hand-held fire extinguisher
35. Sub-woofer (where equipped)
36. Battery ON/OFF switch
37. Center drain plug (accessible under
carpet)
38. Tower with clamping board racks
39. Anchor light and tow point
40. Wireless chargers (where equipped)
41. Battery(ies)
42. Cleat (where equipped)
43. Ballast thru-hull outlet
44. Storage compartment + access to port
side tsunami pump
45. Engine exhaust (two exhaust tips; one
on each side beneath swim platform)
46. Surf tabs (two devices; one on each
side)
47. Swim platform
SPECIFICATIONS
Length of Boat 22’ 0”
Width Amidship 99”
Boat Weight 4,300 lbs.
Length of Boat w/Platform 23’ 10”
Towing Length 27’ 4”
Towing Width 102”
Fuel Capacity 49 G
Maximum Capacity 14 people
or 2,312 lbs.
Bow: 4 people or 600 lbs.
Weight must be evenly distributed.
