2023 OWNER’S MANUAL
/
66
FEATURES
01. Bow cleat
02. Horn
03. Anchor storage
04. Navigation light
05. Ballast tank (below deck)
06. Bow sub-woofer
07. ZeroO GPS puck
08. Ballast thru-hull outlet
09. Bilge thru-hull outlet
10. Midship cleat
11. Instrument panel
12. Steering wheel
13. Throttle control and emergency stop
switch
14. Heated seat
15. Fire suppression unit manual override
16. Sub-woofer (behind helm chair)
17. Wireless cockpit chargers (where
equipped)
18. Cooler (under seat)
19. Convertible center rear seating (where
equipped)
20. Ballast thru-hull outlet
21. Stern cleat
22. Fuel tank fill
23. Engine flush valve
24. Engine compartment
25. Bilge thru-hull outlet
26. Transom remote (where equipped)
27. Surf tab (beneath the platform; two on
each side and one in the center)
28. Center surf tab
29. Bow filler cushion (where equipped)
30. Amp board
31. Trash can door
32. Handheld fire extinguisher
33. Glove box
34. Observer remote (where equipped)
35. Center drain plug
36. Heated observer seat (where
equipped)
37. Batteries ON-OFF switch
38. Tower with clamping board racks
39. Battery or batteries
40. Anchor light; tower tow point
41. Ski pylon attachment point
42. Surf Star ballast bag (where equipped)
43. Automatic fire extinguisher
44. Transom drain plug
45. Swim platform
SPECIFICATIONS
Length of Boat 21’ 10”
Width Amidship 86”
Boat Weight 5,275 lbs.
Length of Boat w/Platform 23’ 10”
Towing Length 26’ 1”
Towing Width 102”
Fuel Capacity 79 gallons Maximum
Capacity 14 people or 2,200 lbs
Bow Capacity: 3 people or 450 lbs
Weight must be evenly distributed
XT22
T
