2023 OWNER’S MANUAL
/
76
NXT24
FEATURES
01. Navigation light
02. Anchor storage compartment
03. Walk-thru door (where equipped)
04. Bilge thru-hull outlet
05. Ballast thru-hull outlets
06. ZeroO GPS puck
07. Cleat (where equipped)
08. Stereo control (on dash, where equipped)
09. Mirror
10. Circuit breaker panel (access under dash)
11. Tilt steering wheel
12. Instrument panel; wireless helm charging
pad (where equipped)
13. Shifter/throttle control
14. Emergency safety stop switch
15. Fire suppression unit manual override
16. Adjustable driver’s seat
17. Access to center ballast pumps
18. Cooler (beneath seat)
19. Sea strainer (in engine compartment)
20. Cleat (where equipped)
21. Ski pylon attachment point
22. Automatic fire extinguisher (inside engine
compartment)
23. Fuel tank filler
24. Ballast thru-hull outlet
25. Bilge thru-hull outlet
26. Transom stereo remote (where equipped)
27. Transom drain plug
28. Center surf tab
29. Navigation light
30. Courtesy light
31. Amp
32. Cleat
33. Glove box
34. Hand-held fire extinguisher
35. Sub-woofer (where equipped)
36. Battery ON/OFF switch
37. Center drain plug (accessible under
carpet)
38. Tower with clamping board racks
39. Tower tow rope attachment and light
40. Wireless cockpit chargers (where
equipped)
41. Battery(ies)
42. Cleat (where equipped)
43. Ballast thru-hull vent
44. Storage compartment + access to port
side tsunami pump
45. Engine exhaust (two exhaust tips; one
on each side beneath swim platform)
46. Surf tabs (two devices; one on each
side)
47. Swim platform
SPECIFICATIONS
Length of Boat 24’ 0”
Width Amidship 85.5”
Boat Weight 5,000 lbs.
Length of Boat w/Platform 26’ 1”
Towing Length 29’ 10”
Towing Width 102”
Fuel Capacity 65 G
Maximum Capacity 16 people
or 2,250 lbs.
Bow: 5 people or 750 lbs.
Weight must be evenly distributed.
