DESCRIPTION
KNOW YOUR DRILL/DRIVER (Fig.1)
PRODUCT SPECIFICATION
Motor 12 Volt DC
Switch VSR (Variable Speed Reversible)
No Load Speed LO 0-400 / HI 0-1300 RPM
Clutch 17+1
Torque 180 in.lbs
Driver Weight (with battery) 2LBs 3OZ
Battery Type Lithium-Ion
Battery Voltage 12 Volt DC
Charger Input 120-Volts, 60 Hz AC only
Optimum Charging Temperature 50°F (10°C) -104°F (40°C)
WARNING! The safe use of this product requires an understanding of the
information on the tool and in this operator’s manual, as well as knowledge of
the project you are attempting. Before use of this product, familiarize yourself
with all operating features and safety rules.
Fig. 1
Battery Pack
Battery Release Button
Torque adjustment ring
Two-speed gearbox switch
Trigger Switch
Vents
Direction of
Rotation Selector
(Forward/Center
Lock/ Reverse)
LED Worklight
