KNOW YOUR ANGLE GRINDER
Before attempting to use any tool, familiarize yourself with all the operating features and safety
requirements.
1. Hand grip areas
2. Anti-vibration auxiliary handle
3. Spindle lock button
4. Disc
5. Wheel guard for grinding
6. Spanner
7. Inner ange
8. Outer ange
9. Clamp adjustment nut
10. Spindle
11. Guard clamping lever
12. Safety on/off switch
13. Variable speed control
14. Wheel guard for cutting*
15. Lock-on button
16. SDS ange
FEATURE
1 12 13
15
5
4
14
2
3
8 76 16
9
10
11
