CUTTING HEIGHT ADJUSTMENT (Fig.8)
The overall height of the trimmer
can be adjusted.
1. Remove the battery pack.
2. Pull the lock collar to loosen the
telescoping shaft.
3. The telescoping shaft can then
be adjusted to be shorter or
longer. When the desired length
is achieved, push the lock collar
to tighten the telescoping shaft.
THREE-POSITION PIVOTING HEAD
(Fig.9)
The trimmer head can be adjusted
to three different positions.
1. Remove the battery pack.
2. Depress the foot pedal and move
the trimmer head up or down
to one of the three positions
indicated by the notches.
NOTE: Adjust the trimmer head
to the first and second position
for trimming. Adjust to the third
position for edging and tilting
function.
3. Make sure the trimmer head
is securely locked into place
before reinstalling the battery
pack.
Fig. 8
Fig. 9
