Mastergrip 690042 - Parts List

ITEM NO. DESCRIPTION QTY. ITEM NO. DESCRIPTION QTY.
1S Air Cap with Ring 1
18 Seat Housing 1
2S
Spray Pattern Adjustment Assembly
1
19 Gasket 1
3S Fluid Control Assembly 1 20 Spring 1
4 Fluid Nozzle 1 21 Air Inlet 1
5 Container Inlet Assembly 1 22 Screw 1
6 Needle Seat 1 23 Spring 1
7 Felt Washer 1 24 Valve 1
8 Air Valve Set 1 25 Air Regulator Housing 1
9 Pivot 1 26 Gasket 1
10 Trigger 1 27 Packing Material 1
11 C-Clip 2 28 Packing Nut 1
12 Valve Stem 1 29 O-Ring 1
13 O-Ring 1 30 Container 1
14 Spray Pattern Cantrol Knob 1 31 Complete Lid Assembly 1
15 Needle Valve 1 32 Gasket 1
16 Body 1
33 Gasket 1
17 Valve Seat 1
PARTS LIST 690042
12
