Mastervolt MAGIC Series User Manual

INSTALLATION 3A: 12/36, 24/36 OR 24/48 CONVERTER
INSTALLATION 3B: 12/36, 24/36 OR 24/48 CONVERTER WITH REMOTE SWITCH
+ –
U-battery
U-out=
0V/ Ubat+13.6V
or
0V/ Ubat+27.2V
DIP switch setting:
DIP switch instelling:
Einstellung des DIP-Schalters:
Réglage cavalier:
Impostazioni interruttore DIP:
Ajuste del conmutador DIP:
- A 12/36, 24/36 or 24/48V converter without galvanic insulation with remote switch function
- Een 12/36, 24/36 of 24/48V converter zonder galvanische scheiding met afstandsbedieningschakelaar
- Ein 12/36, 24/36 oder 24/48V Wandler ohne galvanische Trennung mit Fernschaltfunktion.
- Convertisseur 12/36, 24/36 ou 24/48V sans isolation galvanique avec fonction télécommande.
- Un convertidor de 12/36, 24/36 o 24/48V sin aislamiento galvánico y con función de conmutador a distancia
- Un trasformatore 12/36, 24/36 o 24/48V senza isolamento galvanico con funzione di interruttore a distanza
ON
OFF
Load
Belasting
Last
Charge
Carico
Carga
Model
MAGIC 12/24-10
MAGIC 24/12-20
MAGIC 24/24-20
U-battery
12V
24V
24V
U-out
U-battery + 27.2V
U-battery + 13.6V
U-battery + 27.2V
I-out
10A
20A
20A
ON
OFF
Rear side
Achterzijde
Rückseite
Face arrière
Parte posterior
Indietro
- A 12/36, 24/36 or 24/48V converter
without galvanic isolation.
- Een 12/36, 24/36 of 24/48V converter
zonder galvanische scheiding.
- Ein 12/36, 24/36 oder 24/48V Wandler
ohne galvanische Trennung
- Convertisseur 12/36, 24/36 ou 24/48V
sans isolation galvanique.
- Un convertidor de 12/36, 24/36 o 24/48V
sin aislamiento galvánico
- Un trasformatore 12/36, 24/36 o 24/48V
senza isolamento galvanico.
DIP switch setting:
DIP switch instelling:
Einstellung des DIP-Schalters:
Réglage cavalier:
Ajuste del conmutador DIP:
Impostazioni interruttore DIP:
+ –
U-battery
U-out=
0V / Ubatt+13.6V
or
0V / Ubatt+27.2V
Load
Belasting
Last
Charge
Carico
Carga
Model
MAGIC 12/24-10
MAGIC 24/12-20
MAGIC 24/24-20
U-battery
12V
24V
24V
U-out
U-battery + 27.2V
U-battery + 13.6V
U-battery + 27.2V
I-out
10A
20A
20A
ON
OFF
