MT1815 4 04/30/12
MT1815 Long Barrel Air Hammer
REF. NO. PaRt NO. DEscRiPtiON Qty.
1 RS181501 Housing (Includes Grip #21) 1
2 RS26212 O-Ring 1
3 RS93126 Bushing 1
4 RS93127 Throttle Seat 1
5 RS181105 Throttle Valve 1
6 RS181106 Throttle Spring 1
7 RS181107 Air Inlet 1
8 RS181108 Trigger Button 1
9 RS181109A ** Rubber Bumper 1
10 RS181110 O-Ring 4
11 RS181111 Cylinder Sleeve 1
12 RS181112 Valve Block Assembly 1
REF. NO. PaRt NO. DEscRiPtiON Qty.
13 RS848019 Piston 1
14 RS181514 Cylinder 1
15 * Steel Ball 4
16 * Spring 1
17 * Case Lid (Black) 1
18 * Retaining Ring 1
19 RS181519 Exhaust Deflector 1
20 RS181120 Collar 1
21 Comfort Grip (Incl. w/ #1) 1
* OnlyavailableinChiselRetainerRepairKit,RS1811RK.
** Rubberbumperreplacescushionspringusedpreviouslyinthistool.
