MATE 2-PIN LINE UP TOOL
USAGE INSTRUCTIONS
Step 16
Step 17
16. Remove the Alignment Punch and the piece of sheet metal.
17. Remove the Alignment Die or Die Carrier
18. The station is now aligned.
ALIGNMENT PROCEDURE (CONT.)
