Part List
Part#, Description, Picture , Quantity
Liste de pièces
Numéro de pièces, Description, IIIustration, Quantité
9
Backboard
Pa
nneau
137*82*2.9mm
QTY：1
10
Rim
Anneau
QTY：1
11
Net
Filet
QTY：1
12
Base
Base
QTY：1
13
Backboard Connecting Plate
Plaque de connexion pour panneau
QTY：2
14
Bolt, Washer and Screw Set
Boulon, rondelle et jeu de vis
M8*65mm
QTY：1
15
Bolt, Washer and Screw Set
Boulon,
rondelle et jeu de vis
M10*40mm
QTY：4
16
Bolt,
Washer and Screw Set
Boulon, rondelle et jeu de vis
M8*40mm
QTY：2
7
