Matrix C7xi - Page 7

7
3 4
I
Levelers
Pre-Installed Hardware
Description Qty
I Bolt 5
Torque Value
9.8 Nm / 7.2 ft-lb
C7xi
C7xe
C5x
C3x
C3xe
ASSEMBLY
COMPLETE!
1. Connect the wires from the frame to the Base Step.
2. Lift the Control Zone over the caster wheels. Push
down rmly on both sides until it seats rmly.
3. Slide the Sweat Collector Tray under the
ClimbMill, latching the handle to the base.
C7xi
C7xe
C5x
