7
The NC battery is not charged when you receive it.
The battery must therefore be charged before you
use the tool for the
rst time.
Please refer to the mains voltage shown on the
model plate.
Anewbatterywillreachitsfull capacity after it
hasbeenchargedanddischargedapproximately
ve times.
NC batteries will discharge even if they are not in
use. You should thereforechargethematregular
intervals.
Never discharge the battery completely.
The battery will last for longer if it is used regularly
andthenrecharged.
Tooperate the cordless screwdriver
Charge the battery before you use the cordless
screwdriver for the
rst time.
Switch on
Press the top half of the ON/OFF switch (2) to
make the screwdriver rotate clockwise.
Press the bottom half of the ON/OFF switch (2) to
make the screwdriver rotate anti-clockwise.
Top = Insert screws
Bottom = Removescrews
Switch o
Release the ON/OFF switch (2).
The spindle is locked when the screwdriver is
switched o
. This means that you can use the
screwdriver to insert and remove screws even if
the battery is discharged.
Charge the battery
Connect the power supply (3) to a 220-240 V~ 50
Plugtheadapterintothemainssocketonthe
rear handle of the cordless screwdriver. (B1)
Charge time approx.3-5hours.
Allow the cordless screwdriver to cool before you
recharge it.
Check the charge status of the cordless screw-
driver
Press the button on the right-hand side of the
screwdriver (B2-1).ThreestatusLED’s show the
charge status of the battery.
Red,yellow and green all lit: Batteryfully char-
ged
Red and yellowlit: Battery at half charge
Red lit: Battery almost di
scharged
Working with the cordless screwdriver
Screwdriver bit
Place the requiredscrewdriverbitstraightinto
the chuck on the drive shaftorusethemagnetic
holder as an extension (B3).
General instructions
Ensurethatthebit ts the screw and screw size
precisely.
If youusebitsthataretoosmallortoolarge
youwilldamagethescrewdriverhead.Thisis
particularly important forscrewsthathavetobe
tightened or undone frequently.
Check the di
erence between PZ (Pozidriv) and
PH (Phillips) bits. If you tighten a PZ screw with
a PH bit, you will damage the chuck in the screw
head.
Unsuitable bits may slip o
the screw and cause
injuries.
Technical data
CD 4.8-24 Set
Battery: 4.8 V/0.8 Ah
Speed: no 150 rpm
GB
/60 Hz socket. (Important. Check the voltage on
the model plate).
