11
Z05
Z11
Z27
Z13
Flat Washer (Φ10)
Screw (M10x110L)
Screw (M10x40L)
Nut (M10)
4
2
4
2
Item Description Qty
Z13
Z05x2
Z27x2
Z11
Z13
Z05x2
Z27x2
Z11
NOTE:
Assemble laying down for step 1
Do not completely tighten hardware until final step
GFTWM
Wall Mounted
Step 1 of 3
