GFTVRT
Vertical Extension
Z05x2
Z04x2
Z05
Z04
Flat Washer (Φ10)
Screw (M10x35L)
2
2
Item Description Qty
M10 40 Nm / 30 ft-lb
NOTES:
Tighten hardware from step 3 using
the following
Torque Value:
SLIDE ROM DOWN
1
2
3
Start with the top fastener,
working down, tightening each
bolt two or three revolutions at a
time. Repeat process from top to
bottom until all hardware is fully
threaded.
For use with the Free Standing unit only.
