TOOLS REQUIRED FOR ASSEMBLY (not included)
3MM L-Shaped Allen Wrench 10MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench Phillips Screwdriver
5MM L-Shaped Allen Wrench 8MM Open-End Wrench
6MM L-Shaped Allen Wrench 17MM Open-End Wrench
8MM L-Shaped Allen Wrench Guide Rod Lubrication
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0 mm 10 20 30 40 50 60 70 80 90 100 110 120 130
UNPACKING
Thank you for purchasing a MATRIX Fitness product. It is inspected before it is
packaged. It is shipped in multiple pieces to facilitate the compact packaging of the
machine. Prior to assembly, conrm all the components by matching them with
the exploded diagrams. Carefully unpack the unit from this box and dispose of the
packing materials in accordance with your local laws.
CAUTION
To avoid injury to yourself and prevent damage to the frame components, be sure
to have proper assistance removing the frame pieces from this box. Please be sure
to install the equipment on a stable base, and properly level the machine. Ensure
a minimum clearance width of 0.6 meters (24”) for access to and passage around
MATRIX strength equipment. Please note, 0.91 meters (36”) is the ADA recommended
clearance width for individuals in wheelchairs.
* Use Vibra-Tite 135 Red Gel Threadlocker where nylock nuts are not used.
To Next Page
