Matrix CXP User Manual

6
1 2
A
B
C
B
Red Hardware Pack
Description Qty
A
B
C
Bolt (M12x25L)
Flat Washer
Bolt (M12x70L)
2
4
2
Torque Value
A
C
78 Nm / 58 ft-lb
78 Nm / 58 ft-lb
E
F
D
Yellow Hardware Pack
Description Qty
D
E
F
Stopper
Screw (M8x20L)
Screw (M4x6L)
1
1
2
Torque Value
E 20 Nm / 14 ft-lb
Push to lock
