Revision Date: April 2020
5
FIG. 1
FIG. 2
FIG. 3 FIG. 4
LIFESTYLE CLIMBMILLS
INSTRUCTIONS
Tip the unit forward exposing the leveling feet (Fig. 3), while an assistant adjusts the leveling feet (Fig. 4).
INSTRUCTIONS
Start with the leveling feet all the way up (turn clockwise). Once the Climbmill is placed, the frame should be
resting on the floor. If the Climbmill is not level, adjust the levelers as needed using a 6 mm Allen socket.
1. For Performance & 7, 5 Series frames, remove the dust tray and control zone (Fig. 1).
2. For Endurance & 3 Series frames, remove the end caps to access the levelers (Fig. 2).
TOOLS NEEDED
• 6 mm Allen socket and ratcheting wrench
PERFORMANCE, ENDURANCE & 7, 5, 3 SERIES CLIMBMILLS
LEVELING EQUIPMENT: CLIMBMILLS
CARDIO EQUIPMENT
