3
CHAPTER 2: KranKcycle specifications, parts and assembly steps
2.1 JOHNNY G KRANKCYCLE BY MATRIX SPECIFICATIONS
The Johnny G Krankcycle by Matrix is designed according to EN957-5 standards as a Class S subcategory C product for professional and / or com-
mercial use. Such training equipment is intended for use in training areas of commercial facilities such as Fitness Clubs or Sport Associations,
where access and control is regulated by the person who has legal responsibility. The Johnny G Krankcycle is not suited for theraputic use.
Specifications
Foot print: 56.5”L x 26.8”W x 41.5”H / 1.44m L x 0.68m W x 1.06m H
Weight of bike: 142.4 lbs / 64.6 kg
Saddle height: 24.3” / 0.62m
Max crank arm height: 53.5” / 1.36m
Max user weight: 350 lbs / 159 kg
The Krankcycle is designed to accommodate most users from 150 to 205 cm / 59 to 81 inch body height.
