54
ITALIANO
G
F
H
E
C
D
C
ASSEMBLAGGIO
C
B
2
Hardware Qtà
D
C
Bullone
Rondella piatta
6
6
3
Hardware Qtà
E
C
Bullone
Rondella piatta
6
6
1
Hardware Qtà
A
B
C
Bullone
Rondella elastica
Rondella piatta
8
8
8
4
Hardware Qtà
F
G
H
I
Bullone
Rondella piatta
Vite (20mm)
Vite (10mm)
4
4
2
1
1
4
3
6
2
5
7
1
2
3
4
5
6
7
Comunicazione MCB
Prolunga del cavo di alimentazione
Ethernet
Coassiale
Cavo di terra
Arresto di emergenza
Cavi di collegamento console
ASSEMBLAGGIO COMPLETO
Non stringere i bulloni fino al completamento
delpassaggio 3.
Pre-installato
Stringere tutti i bulloni dei passaggi 1–3.
Utilizzare la fascetta per
fissare il cavo COASSIALE
Rimuovere, attaccare
lacross bar,
poi re-installare
