Matrix LIFESTYLE TOUCH XL User Manual

6
ENGLISH
G
F
H
E
C
D
C
ASSEMBLY
C
B
A
1
Hardware Qty
A
B
C
Bolt
Spring Washer
Flat Washer
8
8
8
Do not tighten bolts until step 3 is complete.
Pre-installed
Use zip tie to secure
COAX cable
2
Hardware Qty
D
C
Bolt
Flat Washer
6
6
3
Hardware Qty
E
C
Bolt
Flat Washer
6
6
Tighten all bolts from steps 1–3.
Remove, attach cross-bar,
then re-install
4
Hardware Qty
F
G
H
I
Bolt
Flat Washer
Screw (20mm)
Screw (10mm)
4
4
2
1
1
4
3
6
2
5
7
1
2
3
4
5
6
7
MCB Communication
Extension Power Wire
Ethernet
Coax
Ground Wire
Emergency Stop
Console Connect Wires
ASSEMBLY COMPLETE

Matrix LIFESTYLE TOUCH XL Specifications

General

Brand	Matrix
Model	LIFESTYLE TOUCH XL
Category	Treadmill
Language	English
