Matrix MD-S70 - Page 11

11
H
B
E
D
F
E
G
D
E
F
3 4
Step 3 Hardware
Description Qty
D
E
F
Hex Head Bolt (M10x20L)
Spring Washer (Φ10.2)
Washer (Φ10.2)
2
2
2
Step 4 Hardware
Description Qty
B
D
E
F
G
H
Arc Washer (Φ10.2)
Hex Head Bolt (M10x20L)
Spring Washer (Φ10.2)
Washer (Φ10.2)
Socket Head Bolt (M10x20L)
Pre-installed Nut (M12)
2
2
4
2
2
1
Cable
ENGLISH
