12
5 6
K
F
J
I F F
C
Step 6 Hardware
Description Qty
C
F
I
J
K
Nut (M10)
Washer (Φ10.2)
Bolt (M10x75L)
Bolt (M10x30L)
Pre-installed Screw (M5x20L)
6
14
6
2
4
ENGLISH
