Matrix MD-S711 User Manual

6
8
7 5 6
5
Starting Leg Position
Pull pin, adjust pad to desired start position, release pin.
Allows the user to adjust the work arm
to a comfortable start position.
8
0.9 kg / 2 lb Increment Weight (optional)
Remove individual incremental weight pins and insert
above head plate to achieve desired starting weight.
6
Thigh Pad Rotation
Pull pin, rotate thigh pad out, release pin.
Allows the user to swing the thigh pad out away from
the user for easy entrance and exit of the machine.
7
Thigh Pad Release
Depress lever with thumb, raise or
lower pad, release lever.
Allows the user to raise or lower the thigh
pad into a comfortable start position.
ADJUSTMENT POINTS
ENGLISH
