Instrument diagram (Figure 1)
(1) Left and right turn indicators: When the turn signal button is turned, the left and
right turn indicators will flash.
(2) High and low beam indicator: When the dimmer switch is turned to the "0" position,
the high and low beam indicator will light up. When the dimmer switch is turned to the
"Multi D" position, the high and low beam indicators will not light up.
(3) Temperature display lamp.
(4) Volume adjustment indicator: adjust the volume.
(5) Multimedia display.
(6) Running speed display.
(7) Gear display.
Neutral indication: When the switch button is in the "N" position,
the gear indicator light "N" will be on.
Reverse indication: When the switch button is in the "R" position,
the reverse indicator light "R" will be on.
Forward indicator: When the switch button is in the "D" position, the
forward indicator light "D" will be on.
