Matrix S7xi - Page 10

10
INCLUDED FASTENERS
Qty: Sketch: Part Name: Bag:
8
SOCKET HEAD BOLT
(M8x16L)
White
8 LOCK WASHER White
2
SOCKET HEAD BOLT
(M8x25L)
Blue
4 LOCK WASHER Black
4
BUTTON HEAD BOLT
(M8x40L)
Black
2 LOCK WASHER Yellow
2
BUTTON HEAD BOLT
(M8x45L)
Yellow
2 SCREW SET Orange
Qty: Sketch: Part Name: Bag:
4
BUTTON HEAD BOLT
(M8x16L)
Orange
8 ARC WASHER Orange
3 LOCK WASHER Green
3
BUTTON HEAD BOLT
(M8x16L)
Green
4
BUTTON HEAD BOLT
(M5x15L)
Red
