Matrix SATATYA NVR Quick Start 6
General Specifications
LAN
(RJ45)
To connect a standalone personal
computer, or a LAN Switch, or to connect
to the Internet over a DSL Modem or
Router.
Ethernet Speed:10/100/1000Mbps
LAN 1 - Present in all variants
LAN 2 - Present in all variants except
NVR0801X and NVR1601X
Audio IN
(RCA)
To connect audio input device such as a
mike.
Yes (1)
Audio OUT
(RCA)
To connect a low impedance earphone,
active sound box or an amplified speaker.
Yes (1)
Reset
Press and hold down the reset button for
atleast 4 seconds to default
the following parameters.
• LAN Settings
• User Settings
• General Settings
Yes
Parameters
NVR0801X, NVR1601X, NVR1602X,
NVR3202X
NVR3204X, NVR6404X, NVR6408X
Power supply 12VDC, 5A SMPS
Operating Temperature 0°C to +50°C (32°F to 122°F)
Humidity 5% to 95% RH Non-Condensing
Interface Description All Variants
