Matrix SATATYA NVR0801X User Manual

7 Matrix SATATYA NVR Quick Start
LED And Buzzer State
The NVRX variants has a set of LEDs and Buzzer for indication of events on the SATATYA NVRX
series. It has been explained in the table below.
State Description Status LED Cadence Power LED Buzzer (System)
Supply is connected but
application is not yet initialized.
OFF
Green
Steady
N.A.
On Application Initialization
Red
1000 - ON and 1000 – OFF
3000 – ON
System in normal state
(Connected to network).
Green
3000-ON and 1000-OFF
N.A.
Storage Incomplete Volume.
Red
1000 ON–5000 OFF
1000 - ON and 5000 – OFF
Storage Full Alert.
Red
2000-ON–2000 OFF
N.A.
Storage Full.
Red
1000 ON–3000 OFF
N.A.
Formatting Disk.
Red
1000 ON–1000 OFF
N.A.
Firmware upgrade in process.
Orange
1000 ON–2000 OFF
N.A.
Firmware upgrade failed.
Red
1000 ON–1000 OFF
1000 - ON and 1000 – OFF
Trigger from Event N.A. N.A 3000 - ON and 1000 – OFF
Backup Device full N.A. N.A 1000 - ON and 2000 – OFF
No Backup Device N.A. N.A 1000 - ON and 3000 – OFF
