18 Matrix SATATYA Devices Manual
NVR16H
NVR64P/NVR64S
NVR Rear Panel Controls
Interface Description NVR8S NVR16S NVR24P NVR16H NVR64S/P
Power
supply
To connect AC/DC
power supply as
specified.
12 VDC,
2A
12 VDC, 5A 12 VDC, 5A 12 VDC, 7A
To connect
100-240
VAC, 50-
60Hz
SENSOR
IN/Alarm In
(Terminal
Block Plug)
To connect a sensor
device to detect alarm
events.
Yes (2) Yes (4) Yes (8) Yes (8) Yes (4)
ALARM
OUT (2)
SENSOR
IN (4)
RESET
LEDs
AUDIO IN
AUDIO OUT
USB 8
USB 5
(SCHEDULED
BACKUP)
USB 6
(MANUAL
BACKUP)
HDMI 1
VGA
IOIOI-
Serial Port
Power
Supply
Fan
LAN 1
LAN 2
USB 7
