Matrix SATATYA NVRX Series - Page 25

Matrix SATATYA Devices Manual 19
ALARM
OUT
(Terminal
Block Plug)
To connect an alarm
sounding relay device
such as a hooter or
siren.
Yes (1) Yes (1) Yes (4) Yes (3) Yes (2)
REMOTE
EXTENDER
(Terminal
Block Plug)
To connect a Remote
IR Receiver.
No No Yes Yes No
HDMI 1
(MAIN)
To connect a high
definition digital
monitor or TV for
Main view.
Yes Yes Yes Yes Yes
HDMI 2
(SPOT)
To connect a high
definition digital
monitor or TV for Spot
view.
No No Yes Yes No
LAN 1
(RJ45)
To connect a
standalone personal
computer, or a LAN
Switch, or to connect
to the Internet over a
DSL Modem or
Router.
Yes Yes Yes Yes Yes
LAN 2
(RJ45)
To connect a
standalone personal
computer, or a LAN
Switch, or to connect
to the Internet over a
DSL Modem or
Router.
No No Yes Yes Yes
VGA OUT
(VGA)
To connect a VGA
type monitor (LCD
monitor of a personal
computer) for local
viewing; to access
NVR controls and
configuration settings
from the display.
Yes Yes Yes Yes Yes
Audio IN
(RCA)
To connect audio
input device such as
a mic.
Yes No Yes No Yes
Audio OUT
(RCA)
To connect a low
impedance earphone,
active sound box or
an amplified speaker.
Yes No Yes No Yes
Interface Description NVR8S NVR16S NVR24P NVR16H NVR64S/P
