20 Matrix SATATYA Devices Manual
RS485 is available in NVR16S, NVR24P, NVR16H, which is not in use.
NVR Rear Panel USB Connections
USB 1-4: Defined for Front Panel (Explained in Front Panel section).
USB 5-6: Defined for Rear Panel.
Reset
Press and hold down
the reset button for
atleast 4 seconds to
default
the following
parameters.
• LAN Settings
• User Settings
• General Settings
• Resolution Settings
No Yes
Yes Yes
Yes
Interface NVR8S NVR16S NVR24P NVR16H NVR64S/P
USB 5 No Yes (Backup) No Yes
Yes (Scheduled
Backup)
USB 6 No Yes (Dongle) No Yes Yes (Backup)
USB 7 No No No No Yes
USB 8 No No No No Yes
Interface Description NVR8S NVR16S NVR24P NVR16H NVR64S/P
