6
J23x3
Z74x8
J40x9
C05
Z60
Z36
C29x4
Z31x4
Z30x4
J24
J24
J03x4
Z74x4
Hardware
Description Qty
J40
J03
Z74
C29
J23
C05
Z60
Z36
Z30
Z31
J24
Caps
Links
Screw (M8X25L)
Short Shaft
Swirl Spring
Axle
Special Flat Washer
Screw (M10X25)
Flat Washer
Lock Washer
Spacer
9
4
12
4
3
1
1
1
4
4
2
2
