Matrix VARSITY VY-400 - Page 6

6
A
C
D
E
1
Step 1 Hardware
Description Qty
A
C
D
E
Screw (M8x20L)
Bolt (M10x25L)
Spring Washer (M10)
Washer (M10)
4
5
5
5
2
C
D
E
E
F
G
Step 2 Hardware
Description Qty
C
D
E
F
G
Bolt (M10x25L)
Spring Washer (M10)
Washer (M10)
Bolt (M10x105L)
Nyloc Nut (M10)
2
2
6
2
2
ENGLISH
