Matrix VARSITY VY-400 - Page 8

8
H
I
K
J
5
Step 5 Hardware
Description Qty
H
I
J
K
Bolt (M12x85L)
Small Washer (M12)
Large Washer (M12)
Nyloc Nut (M12)
4
4
4
4
6
L
E
Step 6 Hardware
Description Qty
L
E
Bolt (M10x75L)
Washer (M10)
4
4
ASSEMBLY COMPLETE!
Pre-installed
Hardware
Pre-installed
Hardware
ENGLISH
