103
O
P
9 10
Passo 10 Hardware
Descrição Qtd.
O
P
Parafuso (M8 x 25L)
Arruela lisa (Φ8,4)
4
4
Valor de torque
15 Nm/11 ft-lb
PORTUGUÊS
