STEP 2 | PAD ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANTITY
4 M10 Flat Washer 6
26 M10 X 25L SHC 6
27 Thigh Pad 1
28 Pad 1
ASSEMBLY
PART 4: PAD ASSEMBLY
28
4
27
26
Install the pad as shown.
Tighten to 57 N-m/41 ft-lbs.
